Specifications and Reference Data
A.11 485 specifications
A.11.1 Performance specifications
Performance statement assumptions
Measured pipe I.D. (or Measured pipe cross sectional area)
Discharge coefficient factor
±0.75% of flow rate
Repeatability
±0.1%
Line sizes
 Sensor Size 1: 2-in. to 8-in. (50 to 200 mm)
 Sensor Size 2: 6-in. to 96-in. (150 to 2400 mm)
 Sensor Size 3: 12-in. to 96-in. (300 to 2400 mm)
Note
Some mounting types are not available in larger line
sizes.
Sizing
Contact an Emerson Process Management representative for
assistance. A Configuration Data Sheet is required prior to
order for application verification. To complete the
Configuration Data Sheet go to:
http://www3.emersonprocess.com/Rosemount/DP_Flow/Ap
plication/Pages/PCDefault.aspx
Flow turndown
10:1 or better
Annubar sensor surface finish
The front surface of the Annubar primary element is textured
for high Reynolds number applications (typically gas and
steam). The surface texture creates a more turbulent
boundary layer on the front surface of the sensor. The
increased turbulence produces a more predictable and
repeatable separation of flow at the edge of the sensor. The
appropriate surface finish will be determined for each
application by the Emerson Process Management sizing
program, Instrument Toolkit software.
A.11.2 Functional specifications
Service
 Liquid
 Gas
 Steam
Process temperature limits
Direct Mount Transmitter
 500 °F (260 °C)
 750 °F (398 °C) when used with a direct mount, high
temperature 5-valve manifold (Transmitter
Connection Platform code 6). Maximum temperature
limit for steam processes is 650 °F (343 °C).
Remote Mount Transmitter
 1250 °F (677 °C) – Alloy C-276 Sensor Material (For
superheated steam applications above 1000 °F
(538 °C), it is recommended that the Rosemount 585
with Alloy 800H sensor material is used.)
 850 °F (454 °C) – Stainless Steel Sensor Material
Table 15. Reynolds Number and Probe Width
Sensor size
Minimum rod
Reynolds
number (R
d
)
Probe width (
d
)
(inches)
1 6500 0.590-in. (14.99 mm)
2 12500 1.060-in. (26.92 mm)
3 25000 1.935-in. (49.15 mm)
Where
d = Probe width (feet)
v = Velocity of fluid (ft/sec)
p = Density of fluid (lbm/ft
3
)
 = Viscosity of the fluid (lbm/ft-sec)
R
d
dv p

---------------------
=
Pressure and temperature limits
(1)
Direct Mount Transmitter
 Up to 600# ANSI (1440 psig at 100 °F [99 bar at 38 °])
 Integral temperature measurement is not available
with flanged mounting type greater than class 600
Remote Mount Transmitter
 Up to 2500# ANSI (6000 psig at 100 °F [416 bar at
38 °C]).
1. Static pressure selection may effect pressure limitations.

Rosemount 3051SFC_A Specifications

General

Brand	Rosemount
Model	3051SFC_A
Category	Measuring Instruments
Language	English
