Rosemount 3051SFC_A User Manual

Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
111
Specifications and Reference Data
A.3.2 Functional specifications
Range and sensor limits
Flowmeter with coplanar sensor module
Flowmeter with MultiVariable sensor module
Minimum span limits
Transmitter with coplanar sensor module (single variable)
Transmitter with multi-variable sensor module
Process temperature RTD interface
(3051SF_1, 3, 5, or 7)
Minimum span = 50 °F (28 °C)
Service
3051SF_5, 6, 7, or D (direct process variable output)
Liquid, gas, and steam applications
3051SF_1, 2, 3, or 4 (mass and energy flow output)
Some fluid types are only supported by certain
measurement types.
Range
DP Sensor (3051SF_3, 4, or 7)
Lower (LRL) Upper (URL)
1 0 inH
2
O (0 mbar) 25.00 inH
2
O (62,16 mbar)
2 0 inH
2
O (0 bar) 250.00 inH
2
O (621,60 bar)
3 0 inH
2
O (0 bar) 1000.00 inH
2
O (2,48 bar)
Range
DP Sensor (3051SF1, 2, 5, or 6)
Lower (LRL) Upper (URL)
1 0 inH
2
O (0 mbar) 25.00 inH
2
O (62,16 mbar)
2 0 inH
2
O (0 bar) 250.00 inH
2
O (621,60 bar)
3 0 inH
2
O (0 bar) 1000.00 inH
2
O (2,48 bar)
Range
Static Pressure Sensor (GP/AP)
Lower (LRL) Upper (URL)
(1)
1. For SP Range 4 with DP Range 1, the URL is 2000 psi (137,9 bar).
3
GP
(2)
: -14.2 psig
(0,97 bar)
AP: 0.5 psia
(34,47 mbar)
2. Inert Fill: Minimum pressure = 1.5 psia (0,10 bar) or -13.2 psig (-0,91
bar).
GP: 800.00 psig
(55,15 bar)
AP: 800.00 psia
(55,15 bar)
4
GP
(2)
: -14.2 psig
(0,97 bar)
AP: 0.5 psia
(34,47 mbar)
GP: 3626.00 psig
(250,00 bar)
AP: 3626.00 psia
(250,00 bar)
Process temperature RTD interface (3051SF_1, 3, 5 or 7)
(1)
1. Transmitter is compatible with any Pt 100 RTD sensor. Examples of
compatible RTDs include Rosemount Series 68 and 78 RTD
Temperature Sensors.
Lower (LRL) Upper (URL)
-328 °F (-200 °C) 1562 °F (850 °C)
Range
DP Sensor (3051SF_D, 3, 4 or 7)
Ultra & Ultra for Flow Classic
1 0.5 inH
2
O (1,24 mbar) 0.5 inH
2
O (1,24 mbar)
2 1.3 inH
2
O (3,23 mbar) 2.5 inH
2
O (6,22 mbar)
3 5.0 inH
2
O (12,43 mbar) 10.0 inH
2
O (24,86 mbar)
Range
DP Sensor (3051SF_1, 2, 5, or 6)
Ultra for Flow Classic MV
1 0.5 inH
2
O (1,24 mbar) 0.5 inH
2
O (1,24 mbar)
2 1.3 inH
2
O (3,23 mbar) 2.5 inH
2
O (6,22 mbar)
3 5.0 inH
2
O (12,43 mbar) 10.0 inH
2
O (24,86 mbar)
Range
Static pressure sensor (GP/AP)
Ultra for Flow Classic MV
3 4.0 psi (275,79 mbar) 8.0 psi (551,58 mbar)
4 18.13 psi (1,25 bar) 36.26 psi (2,50 bar)
