Rosemount 3051SFC_A User Manual

Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
109
Specifications and Reference Data
A.3 3051SF specifications
A.3.1 Performance specifications
Performance assumptions include: measured pipe I.D, transmitter is trimmed for optimum flow accuracy, and performance is
dependent on application parameters.
Dynamic performance
Table 3. MultiVariable Flow Performance - Flow Reference Accuracy (Measurement Type1)
(1)(2)
1. Measurement Types 2 - 4 assume that the unmeasured variables are constant. Additional uncertainty will depend on the variation in the
unmeasured variables.
2. Range 1 flowmeters experience an additional uncertainty up to 0.9%. Consult your Emerson Process Management Representative.
3051SFA Annubar Flowmeter
Classic MV (8:1 flow turndown) Ultra for flow (14:1 flow turndown)
Ranges 2-3 ±1.15% of flow rate ±0.80% of flow rate
3051SFC_A Compact Annubar Flowmeter - Annubar Option A
Classic MV (8:1 flow turndown) Ultra for Flow (14:1 flow turndown)
Ranges 2-3
Standard ±1.60% of flow rate ±1.55% of flow rate
Calibrated ±1.00% of flow rate ±0.80% of flow rate
Table 4. Flow Performance - Flow Reference Accuracy (Measurement Type D)
(1)(2)(3)
1. For Measurement Types 5 - 7, refer to the Reference Accuracy specification for the 3051SMV with Measurement Type P.
2. These flow measurement accuracies assume a constant density, viscosity, and expansibility factor.
3. Range 1 flowmeters experience an additional uncertainty up to 0.9%. Consult your Emerson Process Management Representative for exact specifications.
3051SFA Annubar Flowmeter
Classic (8:1 flow turndown) Ultra (8:1 flow turndown) Ultra for flow (14:1 flow turndown)
Ranges 2-3 ±1.25% of flow rate ±0.95% of flow rate ±0.80% of flow rate
3051SFC_A Compact Annubar Flowmeter - Annubar Option A
Classic (8:1 flow turndown) Ultra (8:1 flow turndown) Ultra for flow (14:1 flow turndown)
Ranges 2-3
Uncalibrated ±1.70% of flow rate ±1.65% of flow rate ±1.55% of flow rate
Calibrated ±1.25% of flow rate ±0.95% of flow rate ±0.80% of flow rate
Total time response at 75 °F (24 °C), includes dead time
(1)
1. For FOUNDATION Fieldbus (output code F), add 52 ms to stated values (not including segment macro-cycle).
For option code DA2, add 45 ms (nominal) to stated values.
3051SF_D 3051SF_1, 2, 5, or 6 3051SF_3, 4, or 7
DP Ranges 2-5: 100 ms
Range 1: 255 ms
Range 0: 700 ms
DP Range 1: 310 ms
DP Range 2: 170 ms
DP Range 3: 155 ms
AP & GP: 240 ms
DP Ranges 2-5: 145 ms
DP Range 1: 300 ms
DP Range 0: 745 ms
Dead time
(1)
1. For option code DA2, dead time is 90 milliseconds (nominal).
3051SF_D 3051SF_1-7
45 ms (nominal)
DP: 100 ms
AP & GP: 140 ms
RTD Interface: 1 s
