Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
108
Specifications and Reference Data
Alarm limit
(21)(22)
D 1-7
C7 Custom alarm and saturation levels, low alarm • • ★
C8 Low alarm (standard Rosemount alarm and saturation levels) • • ★
Hardware adjustments and ground screw
D1
(21)(22)(32)
Hardware adjustments (zero, span, alarm, security) • — ★
D4
(33)
External ground screw assembly • • ★
DA
(21)(22)(32)
Hardware adjustments (zero, span, alarm, security) and external ground screw
assembly
• — ★
Conduit plug
DO 316 SST conduit plug • • ★
Conduit electrical connector
(34)
ZE M12, 4-pin, male connector (eurofast
®
) • • ★
ZM A size Mini, 4-pin, male connector (minifast
®
) • • ★
Typical model number: 3051SFC 1 C S 060 N 065 T 3 2 J A 1A 3
1. Available with primary element technology P only.
2. For the 10-in. (250 mm) and 12-in. (300 mm) line size, the alignment ring must be ordered (Installation Accessories).
3. 10-in. (250 mm) and 12-in. (300 mm) line sizes not available with Primary Element Technology code A.
4. For 2-in. (50 mm) line sizes the Primary Element Type is 0.6 for Primary Element Technology Code C.
5. Required for Measurement Type codes 2, 4, 6, and D.
6. Only available with Transmitter Feature Board Measurement Type: 1, 3, 5, 7.
7. Required for Measurement Type codes 3, 4, 7, and D.
8. For Measurement Type 1, 2, 5, and 6 with DP range 1, absolute limits are 0.5 to 2000 psi (0,03 to 137,9 bar) and gage limits are -14.2 to 2000 psig (-0,98
to 137,9 bar).
9. Requires PlantWeb housing.
10. Only intrinsically safe approval codes apply.
11. Only available with Measurement Types D and 6.
12. Only available with output code X.
13. Available with output code A only.
14. For detailed specifications see“Performance specifications” on page 109.
15. Only available with differential pressure ranges 2 and 3, and silicone fill fluid.
16. Long-life Power Module must be shipped separately, order Part No. 00753-9220-0001.
17. Available with primary element technology C only.
18. Available with primary element technology C or A only.
19. For Annubar Option A, consult factory for pipe schedules other than Sch. 40.
20. Available with primary element technology C or P only.
21. Not available with Output Protocol code F.
22. Not available with output code X. Only available with Measurement Type D.
23. Materials of Construction comply with metallurgical requirements within NACE MR0175/ISO for sour oil field production environments. Environmental
limits apply to certain materials. Consult latest standard for details. Selected materials also conform to NACE MR0103 for sour refining environments.
24. Not available with M20 or G
1
/2 conduit entry size.
25. Not available with housing code 7J.
26. Not available with output code F, option code DA2, or option code QT.
27. See the 3051S Reference Manual (document number 00809-0100-4801) for cable requirements. Contact an Emerson Process Management representative
for additional information.
28. Not available with Housing code 00, 5A, 5J, or 7J. External ground screw assembly (option code D4) is included with the T1 option. The T1 option is not
needed with FISCO Product Certifications.
29. Includes Hardware Adjustments (option code D1) as standard. Not available with output code X. Only available with Measurement Type D.
30. Requires Rosemount Engineering Assistant version 5.5.1 to configure.
31. -58°F (50°C) for Measurement Type 1-7.
32. Not available with housing style codes 2E, 2F, 2G, 2M, 5A, 5J, or 7J.
33. This assembly is included with options EP, KP, E1, N1, K1, ND, E4, E7, K7, E3, KA, KC, KD, IA, T1, EM, and KM.
34. Not available with Housing code 5A, 5J, or 7J. Available with Intrinsically Safe approvals only. For FM Intrinsically Safe; Nonincendive (option code I5) or FM
FISCO Intrinsically Safe (option code IE), install in accordance with Rosemount drawing 03151-1009.
Table 2. Rosemount 3051SFC Compact Flowmeter Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
