Specifications and Reference Data
A.15 405 Specifications
A.15.1 Performance specifications
Line sizes
 2-in. (50 mm)
 3-in. (80 mm)
 4-in. (100 mm)
 6-in. (150 mm)
 8-in. (200 mm)
 10-in. (250 mm) special only
 12-in. (300 mm) special only
Sizing
Contact an Emerson Process Management sales
representative assistance. A “Configuration Data Sheet”
is required prior to order for application verification.
A.15.2 Functional specifications
Service
 Liquid
 Gas
 Vapor
Process temperature limits
Direct Mount Transmitter
 -40 to 450 °F (-40 to 232 °C)
Remote Mount Transmitter
 -148 to 850 °F (-100 to 454 °C) – Stainless Steel
Differential pressure limits
Primary element technology A
Maximum working pressure
Pressure retention per ANSI B16.5 600# or DIN PN100
Vibration limits
405A
Assembly to a transmitter
Select option code C11 for the Rosemount 3051S Transmitter
(or option code S3 for the Rosemount 3051C Transmitters) to
factory assemble the Rosemount 405 to a Rosemount
Pressure Transmitter. If the 405 and transmitter are not
factory assembled, they may be shipped separately. For a
consolidated shipment, inform the Emerson Process
Management representative when placing the order.
Table 27. 405A Compact Annubar Sensor
Technology
K Factor uncertainty
All Sizes ±1.00%
Table 28. Maximum Allowable DP (Measurement
in inH
2
O [bar])
Line size
Max DP @ < 450 °F
(200 °C)
Max DP @
450-850 °F
(200-454 °C)
2 (50 mm) 1500 (3.73) 1500 (3.73)
3 (80 mm) 900 (2.24) 790 (1.97)
4 (100 mm) 570 (1.42) 500 (1.24)
6 (150 mm) 290 (0.72) 250 (0.62)
8 (200 mm) 190 (0.47) 160 (0.40)
10 (250 mm)
(1)
1. Only available as a special, EXXXX.
130 (0.32) 110 (0.27)
12 (300 mm)
(1)
100 (0.25) 80 (0.20)
Qualified per IEC61298-3 (1998) for field with low
vibration level or pipeline with low vibration level
(10-60 Hz 0.15 mm displacement peak amplitude/60 -
2000Hz 2g).
(1)
The weight and length of the transmitter assembly shall
not exceed 9.8 lbs (4.45 kg) and 8.60-in. (218.44 mm).
1. Stainless steel temperature housing is not recommended with
primary element technology A in applications with mechanical
vibration.
