Reference Manual
00809-0100-4809, Rev DA
Section 2: Installation
September 2015
Installation
2.5.8 Flo-Tap models
Gas
Figure 2-11. Gas Service
Direct mount
Horizontal gas Vertical gas
Remote mount
Horizontal gas Vertical gas
Recommended zone
30°
360°
Flow
