Appendix A: Specifications and Reference Data
September 2015
170
Specifications and Reference Data
A.13 585 specifications
A.13.1 Performance specifications
Performance statement assumptions
Measured pipe I.D.
Discharge coefficient factor
±1.50% of flow rate
Repeatability
±0.10%
Line sizes
 Sensor size 11: 4-in. to 24-in. (100 to 600 mm)
 Sensor size 22: 6-in. to 36-in. (150 to 900 mm)
 Sensor size 44: 10-in. to 96-in. (250 to 2400 mm)
Sizing
Contact an Emerson Process Management representative for
assistance. A Configuration Data Sheet is required prior to
order for application verification. To complete the
Configuration Data Sheet go to:
http://www3.emersonprocess.com/Rosemount/DP_Flow/Ap
plication/Pages/PCDefault.aspx
Flow turndown
10:1 or better
A.13.2 Functional specifications
Service
 Liquid
 Gas
 Steam
Process temperature limits
Note
Specification is 600 °F (315 °C) in steam service.
Pressure and temperature limits
Table 20. Reynolds Number and Probe Width
Sensor
size
Minimum rod
Reynolds number
(R
d
)
Probe width (
d
)
(inches)
11 6500 0.80-in. (20,32 mm)
22 10000 1.20-in. (30,48 mm)
44 25000 2.28-in. (57,91 mm)
Where
d = Probe width (feet)
v = Velocity of fluid (ft/sec)
p = Density of fluid (lbm/ft
3
)
 = Viscosity of the fluid (lbm/ft-sec)
R
d
dv p

---------------
=
Table 21. Direct Mount Transmitter Connection
Platform
Transmitter connection platform
Temperature
limit
3-valve manifold (Option code 3) 500 °F (260 °C)
5-valve manifold (Option code 6) 750 °F (398 °C)
Table 22. Remote Mount Transmitter Connection
Platform
Sensor material Temperature limit
316 Stainless Steel (Option code S) 850 °F (454 °C)
Alloy C-276 (Option code H) 1250 °F (677 °C)
Alloy 800H (Option code W) 1500 °F (816 °C)
PVDF (KYNAR) (Option code K) 250 °F (121 °C)
Table 23. Main Steam Line Annubar Sensor
Mounting material
Sensor material Max. Pressure @ temp. Max. temp.
Chrome-Moly Grade F-11 Alloy 800H 2317 psig @ 1000 °F (160 bar @ 538 °C) 1100 °F (593 °C)
Chrome-Moly Grade F-22 Alloy 800H 2868 psig @ 1000 °F (198 bar @ 538 °C) 1100 °F (593 °C)
Chrome-Moly Grade F-91 Alloy 800H 3788 psig @ 1100 °F (261 bar @ 593 °C) 1200 °F (649 °C)
