Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
110
Specifications and Reference Data
Mounting position effects
Vibration effect
Power supply effect
Less than ±0.005% of calibrated span per volt change in
voltage at the transmitter terminals
Electro Magnetic Compatibility (EMC)
Transient protection (option T1)
Meets IEEE C62.41.2-2002, Location Category B
6 kV crest (0.5 s - 100 kHz)
3 kA crest (8 ⫻ 20 microseconds)
6 kV crest (1.2 ⫻ 50 microseconds)
Meets IEEE C37.90.1-2002 Surge Withstand Capability
SWC 2.5 kV crest, 1.0 MHz wave form
Update rate
(1)
3051SF_D 3051SF_1-7
22 updates per sec.
DP: 22 updates per sec.
AP & GP: 11 updates per sec.
RTD Interface: 1 update per sec.
Calculated Variables:
Mass/Volumetric flow rate: 22 updates per sec.
Energy flow rate: 22 updates per sec.
Totalized Flow: 1 update per sec.
1. Does not apply to Wireless (output code X). See “Wireless self-organizing networks” on page 114 for wireless update rate.
Models Ultra, Ultra for Flow, Classic and Classic MV
3051SF_3, 4, 7, or D Zero shifts up to ±1.25 inH
2
O (3,11 mbar), which can be zeroed
Span: no effect
3051SF_1, 2, 5, or 6
DP Sensor: Zero shifts up to ±1.25 inH
2
O (3,11 mbar), which can be zeroed
Span: no effect
GP/AP Sensor: Zero shifts to ±2.5 inH
2
O (6,22 mbar), which can be zeroed
Span: no effect
Less than ±0.1% of URL when tested per the requirements of
IEC60770-1 field with general application or pipeline with low
vibration level (10-1000 Hz test frequency range, 0.15mm
displacement peak amplitude, 20m/s2 acceleration
amplitude).
(1)
1. Stainless steel temperature housing is not recommended with
primary element technology A in application with mechanical
vibration.
Meets all relevant requirements of EN 61326 and NAMUR
NE-21.
(1)(2)
1. NAMUR NE-21 does not apply to wireless output code X.
2. 3051SMV and 3051SF_1, 2, 3, 4, 5, 6, 7 requires shielded cable for
both temperature and loop wiring.
