Reference Manual
00809-0100-4809, Rev DA
Appendix A: Specifications and Reference Data
September 2015
174
Specifications and Reference Data
Primary element type
040 0.40 Beta ratio () ★
065
(5)
0.65 Beta ratio () ★
Transmitter connection
D3 Direct mount ★
R3 Remote mount, NPT connections ★
A3
(6)
Traditional, Direct mount, 3-valve Integral Manifold with adapter plate, SST
Options (include with selected model number)
Extended product warranty
WR3 3-year limited warranty ★
WR5 5-year limited warranty ★
Installation accessories
A
(2)
ANSI alignment ring (150#) ★
C
(2)
ANSI alignment ring (300#) ★
D
(2)
ANSI alignment ring (600#) ★
G DIN alignment ring (PN 16) ★
H DIN alignment ring (PN 40) ★
J DIN alignment ring (PN 100) ★
B JIS alignment ring (10K)
R JIS alignment ring (20K)
S JIS alignment ring (40K)
Remote adapters
E Flange adapters 316 SST (
1
/2-in. NPT) ★
High temperature application
T Graphite valve packing (T
max
= 850 °F)
Flow calibration
WC
(7)
Discharge coefficient verification (3 point)
WD
(8)(9)
Discharge coefficient verification (full 10 point)
Pressure testing
P1 Hydrostatic testing
Special cleaning
P2
(10)
Cleaning for special processes
PA Cleaning per ASTM G93 level D (section 11.4)
Table 26. Rosemount 405C Compact Primary Element Ordering Information
★ The Standard offering represents the most common options. The starred options (★) should be selected for best delivery.
__The Expanded offering is subject to additional delivery lead time.
