Reference Manual
00809-0100-4663, Rev BA
January 2010
F-3
Rosemount 8732
FREE_SPACE 24 This parameter represents the percent of memory available for further
configuration (zero in a preconfigured device).
FREE_TIME 25 This parameter represents the percent of the block processing time that is free to
process additional blocks.
GRANT_DENY 14 Options for controlling access of host computers and local control panels to
operating, tuning, and alarm parameters of the block (not used by the device).
HARD_TYPES 15 HARD_TYPES shows the types of hardware available as channel numbers. For
the Rosemount 8732, this parameter is limited to scalar (i.e., analog) inputs.
HARDWARE_REV 52 This parameter represents the hardware revision of the hardware that has the
resource block in it.
HEALTH_INDEX 84 Parameter representing the overall health of the device, 100 being perfect and 1
being non-functioning. The value is based on the active PWA alarms.
ITK_VER 41 FOUNDATION fieldbus Interoperability Test Kit Version
LIM_NOTIFY 32 Maximum number of unconfirmed alert notify messages allowed.
MAINT_ACTIVE 77 Active maintenance alarms.
MAINT_ALM 78 Alarm indicating the device needs maintenance soon. If the condition is ignored,
the device will eventually fail.
MAINT_PRI 74 Designates the alarming priority of the maintenance alarm.
MAINT_ENABLE 75 Enables or disables the maintenance conditions within a device.
MAINT_MASK 76 Mask of Maintenance Alarm. Corresponds bit for bit to the Maintenance Active. A
bit on means that the failure is masked out from alarming.
MANUFAC_ID 10 Manufacturer identification number—used by an interface device to locate the DD
file for the resource (001151 for Rosemount).
MAX_NOTIFY 31 Maximum number of unconfirmed alert notify messages possible.
MEMORY_SIZE 22 Available configuration memory in the empty resource. To be checked before
attempting a download.
MESSAGE_DATE 57 MESSAGE_DATE is the date associated with the MESSAGE_TEXT parameter.
MESSAGE_TEXT 58 MESSAGE_TEXT is used to indicate changes made by the user to the device's
installation, configuration, or calibration.
MIN_CYCLE_T 21 Time duration of the shortest cycle interval of which the resource is capable.
MISC_OPTION 47 Indicates which miscellaneous licensing options are enabled.
MODE_BLK 05 The actual, target, permitted, and normal modes of the block:
Target: The mode to “go to”
Actual: The mode the “block is currently in”
Permitted: Allowed modes that the target mode may take on
Normal: Most common mode for the actual mode
NV_CYCLE_T 23 NV_CYCLE_T is the interval between which copies of nonvolatile (NV) parameters
are written to NV memory. Zero denotes that NV parameters are never written to
NV memory.
OUTPUT_BOARD_SN 53 This parameter represents the output board serial number.
PWA_SIMULATE 85 Parameter allows simulation of PWA alarms.
RB_SFTWR_REV_ALL 51 Software revision string containing the following fields: major revision, minor
revision, build, time of build, day of week of build, month of build, day of month of
build, year of build, initials of builder.
RB_SFTWR_REV_BUILD 50 This parameter shows the build of software that the resource block was created
with.
RB_SFTWR_REV_MAJOR 48 This parameter shows the major revision of the software that the resource block
was created with.
RB_SFTWR_REV_MINOR 49 This parameter shows the minor revision of the software that the resource block
was created with.
RECOMMENDED_ACTION 68 Enumerated list of recommended actions displayed with an alert.
Index Number
Parameter Rev 5 Description
