Rotax 914 series Maintenance Manual

76-00-00
page 22
May 01/2007
Effectivity 914 Series
Edition 1 / Rev. 0
d02626
BRP-Rotax
Maintenance Manual
◆ NOTE: Because of the multitude of displays, param-
eters important for the user are printed in bold
type and underlined.
MONITOR: Serves for the on-line display of operational
engine data such as airbox pressure, ambient
pressure, servo position, airbox temperature
etc.
LOG: Is a submenu (18) of the MONITOR program
and facilitates recording of current operational
data on the hard disk of the connected PC.
Logging is activated and stopped by pressing
the key L. The logging status is indicated by
“ON” for on-line recording and “OFF” respec-
tively for non-recording (see Fig. 76-14, item
(5)).
A so-called Log file will be loaded onto the hard
disk stating date and starting time of the
recording.
Example:
◆ NOTE: Verify this date and starting time when booting
the PC.
If more than 4000 data lines are recorded, the
current LOG file will be closed automatically
and a new one opened.
00193
Fig. 76-15
11061014.LOG
Minute (minute)
Stunde (hour)
Tag (day)
Monat (month)

Rotax 914 series Specifications

General

Bore	79.5 mm
Stroke	61 mm
Compression Ratio	9.0:1
Cooling System	Liquid-cooled cylinder heads, air-cooled cylinders
Redline	5800 rpm
Engine Type	4-cylinder, 4-stroke
Fuel Type	Avgas 100LL
Oil System	Dry sump
Fuel System	fuel injection
TBO (Time Between Overhauls)	2000 hours
Displacement	1.211 liters (1211 cc)
Power Output	84.6 kW (115 hp) at 5, 800 rpm
