Rotax 914 series Maintenance Manual

BRP-Rotax
Maintenance Manual
72-00-00
page 80
May 01/2007
Effectivity 912/914 Series
Edition 1 / Rev. 0
d02622
3.13.3) Piston pin
See Fig. 72-90
Measure piston pin and check for traces of seizure in area of con-rod
seat. In case of distinct traces of seizure, replace piston pin even if
dimensions are correct.
Measure dimension PI03.
See 72-00-00 sec. 4.
◆ NOTE: The mono hook circlips for axial piston pin circlip must
be used only once and must therefore be replaced.
PI03
07403
Fig. 72-90

Rotax 914 series Specifications

General

Bore	79.5 mm
Stroke	61 mm
Compression Ratio	9.0:1
Cooling System	Liquid-cooled cylinder heads, air-cooled cylinders
Redline	5800 rpm
Engine Type	4-cylinder, 4-stroke
Fuel Type	Avgas 100LL
Oil System	Dry sump
Fuel System	fuel injection
TBO (Time Between Overhauls)	2000 hours
Displacement	1.211 liters (1211 cc)
Power Output	84.6 kW (115 hp) at 5, 800 rpm
