IQ3 Full Configuration Manual – Section: Settings 35
2.6 Settings – Defaults
Settings
Limits
Indication
Control
ESD
Security
Defaults
Settings
Restore Default Settings
Copy Current to Default
Limits
Restore Factory Limits
3/3
Allows default settings and factory set limits to be restored.
Settings
1/3 Restore
All IQ functions are configured to Rotork default settings before
despatch. If requested at time of order, alternative user specified
settings will be set.
When valve maker and site commissioning takes place, any
settings entered will overwrite the factory default settings and
will be the current settings used in operation along with the
remaining unadjusted defaults.
Should difficulty be encountered during commissioning
the default settings can be restored, returning the actuator
configuration to its default settings.
Standard default settings are indicated in this manual.
To restore the default settings, .
A warning will be given, to continue .
All settings must then be checked/set as required for
valve operation and process control/indication.
2/3 Copy
High level access only. Refer to 2.5 Security.
Once satisfactorily commissioned and tested, the current
settings can be copied to become the new default settings. In
future, restoring the default settings will return the actuator
configuration to its site commissioned setup. Refer to 1/3
Restore. If Rotork are contracted to commission the actuator, on
completion and agreement, current settings will be copied to
defaults.
After entering the High level password,
.
A warning will be given, to continue .
The current settings shown on each setting page will be
copied to defaults.
Limits
3/3 Restore
This setting will restore the factory set limit positions and position
the actuator at 50% open. Factory limits: 25 output turns (or
quarter-turn for IQT) between Closed and Open Limit positions.
To restore the default Limits, .
A warning will be given, to continue .
Closed and Open Limits must be reset to the valve.
Refer to 2.1
