IQ3 Full Configuration Manual – Section: Assets 63
5.1.2 Actuator – Actuator Std Build
Open Limit
User Interface
Serial No SERIAL USER INTERFACE
Software Version v104 (3708)
BT Mac 00:07:80:5a:80:43
FCC ID: QOQWT12
IC: 5123A-BGTWT12A
Telec R 205 WW 2010067
Control Board
1/22
Actuator Standard Build Information
This screen allows the user to view the standard build details of
the actuator. All information shown is read only.
To scroll through this information use and .
User Interface
1/22 Serial No – Displays the serial number of the user interface
module.
3/22 Software Version – Displays the software version of the
user interface module.
4/22 BT Mac – Displays the Bluetooth MAC address of the user
interface module.
5/22 FCC ID: – Displays the user interface modules Federal
Communications Commission Bluetooth identification.
6/22 IC: – Displays the user interface modules Industry Canada
Bluetooth identification.
7/22 Telec R – Displays the user interface modules Telecom
Engineering Center Bluetooth identification.
Control Board
8/22 Serial No – Displays the serial number of the control board.
10/22 Software Version – Displays the software version of the
control board.
11/22 SIL SW Version – Displays the software version of the
control board for SIL actuators.
Position Sensor
12/22 Serial No – Displays the serial number of the position sensor.
14/22 Software Version – Displays the software version of the
position sensor.
15/22 Hardware Version – Displays the hardware version of
the position sensor of SIL actuators.
16/22 SIL SW Version – Displays the software version of the
position sensor for SIL actuators.
Torque Sensor
17/22 Serial No – Displays the serial number of the torque sensor.
IQT3 Motor Control Board
19/22 Software Version – Displays the software version of the
IQT3 Motor Control Board.
20/22 Serial No – Displays the serial number of the IQT3 Motor
Control Board.
Battery Back Up
22/22 Software Version – Displays the software version of the
Battery Back Up.
5.1.3 Actuator – Actuator Opt Build
Close Limit
Option1
Type Analogue
Serial No 1227BX0160002901=10
Software Version v105 ( 843)
Option2
Type Relays
Serial No 1216BX0250004802=12
Software Version v102 ( 1919)
1/16
Actuator Option Build Information
This screen allows the user to view the details for any options
fitted to the actuator. Up to four options can be fitted to the IQ3
(this is dependent on number of terminals available and inter-
option compatibility).
To scroll through this information use and .
Option 1
1/16 Type – Displays the type of option fitted.
2/16 Serial No – Displays the serial number of the option board
fitted.
4/16 Software Version – Displays the software version of the
option fitted.
Option 2
5/16 Type – Displays the type of option fitted.
6/16 Serial No – Displays the serial number of the option board
fitted.
8/16 Software Version – Displays the software version of the
option fitted.
Option 3
9/16 Type – Displays the type of option fitted.
10/16 Serial No – Displays the serial number of the option
board fitted.
12/16 Software Version – Displays the software version of the
option fitted.
Option 4
13/16 Type – Displays the type of option fitted.
14/16 Serial No – Displays the serial number of the option
board fitted.
16/16 Software Version – Displays the software version of the
option fitted.
