23/05/2019Roundshot VR Drive Instruction Manual – Firmware Version 2.023 134
At this stage the sequence from starting point to point 1 is
defined.
Click on new point to define the next sequence point. As for the
point 1 define the position, image interval (if applicable),
acceleration, duration and pause.
Repeat this process until the video or timelapse sweep sequence
is fully defined.
Click on end of point acquisition to finish the timelapse or video
program. You can now start the program and edit any value if
necessary.
Point acquisition
end of point
acquisition
new point
Please note that the point creation is the same for all hardware types. The only
difference is the point position values. They can either be defined in degrees or in cm
depending on the configuration.
The VR Drive is delivered with the correct parameters for your hardware
configuration. However if the dolly or linear rail are ordered later, it is possible to
adjust their dimensions on the VR Drive.
In the “Settings”-> “General” menu edit one of the
following parameters:
• Diameter linear axis: to change the size of the wheel
used on your linear axis. Contact Seitz to get the
correct size for your hardware configuration
• Rot direction linear axis: to define the positive
rotation direction of the main wheel of the linear
axis. Choose between CW or CCW
• Diameter dolly wheels: to change the size of the
wheels used on your dolly. Contact Seitz to get the
correct size for your hardware configuration
manual
movement
default
movement
manual
movement
off in
Parkposition
yes
general
auto exposure
ranges
Radio
off
diameter dolly
Wheels
200mm
rot. direction
linear axis
CW
diameter
linear axis
151mm
general
6.8 Video vs. timelapse mode (continued)
