23/05/2019Roundshot VR Drive Instruction Manual – Firmware Version 2.023 6
1.1 Hardware components + accessories (continued)
Roundshot VR Drive “full”
VR Drive x-motor
touch screen
on/off button
VR Drive y-motor
quick adaptor
quick adaptor release
VR bracket lock
VR bracket
nodal rail
nodal rail clamp
x-motor cable
charging unit
release cable
USB cable
Ethernet (to
connect wifi
module)
VR Drive components
1
2
3
4
5
6
7
8
9
10
11
12
13
1
2
3
4
5
8
9
13
19
20
21
22
23
17
15
release cable (optional)
USB cable for camera
control (optional)
motor cable x-y
spirit level
tripod mount (3/8’’)
VR Drive y-motor
cable clips
socket for radio control
unit (receiver)+ for light
meter
14
15
cables/plugs
6
16
10
11
18
12
17
18
7
11
12
13
14
16
17
17
17
