RTK 725 Series User Manual

RTK Series 725 Annunciator
52
17. Common Pushbutton Module
17.1 P725 Systems Sharing A Common Pushbutton / Programme Module
Multiple Series 725 Annunciators can be supplied with one common pushbutton / programming
module to allow a number of cabinets to operate as a single system.
Each of the cabinets will be equipped with an additional card “option SI/O” which provides 24VDC
power connections and in / out ribbon sockets to allow all system connections, (First-Out Groups,
Horn Groups, Common Alarm Groups and Pushbutton Control), to be easily connected between
units.
A maximum of 256 alarm channels, distributed in cabinets to suit individual applications, can share a
single pushbutton / programming module
Multiple Annunciators Sharing A Common Programming / Pushbutton Module
UPTO A MAX OF 256
ALARM CHANNELS
