RTK 725 Series User Manual

RTK Series 725 Annunciator
62
21. Function No Key And Descriptions
If units are supplied with unarmed alarm channels it is necessary to jump over these missing cards
(addresses) to access the next channel.
General Description
The P725 is equipped with numerous pre-defined features that can be simply enabled or disabled on
a per channel basis as required. Functions numbers are assigned to each feature for ease of
selection.
Feature and Function Key
FEATURE FUNCTION
STATUS LED
OFF ON
Monitor current input contact state FO
Alarm Contact
Open
Alarm contact
closed
Set signal contact non alarm state F1
Normally
Open
Normally
closed
Set individual channel repeat
Relay non alarm state
F2
Normally
energised
Normally
de-energised
Set automatic or manual
Reset function
F3
Manual
Reset
Automatic
reset
Set fleeting alarm state F4 Lock in Non lock in
Set alarm to ringback sequence F5 N/A Ringback
Pushbutton interlock F6 Enable Disable
Input reflash F7 Disable Enable
Reflash critical group relay F8 Disable Enable
Reflash non critical group relay F9 Disable Enable
Set alarm to first up sequence F0 F10* Disable Enable
Set alarm to first up sequence F1 F11 Disable Enable
Set alarm to first up sequence F2 F12 Disable Enable
Set alarm to first up sequence F3 F13 Disable Enable
Set alarm to be in first up group A F14* Disable Enable
Set alarm to be in first up group B F15 Disable Enable
Set alarm to be in first up group C F16 Disable Enable
Set alarm to be in first up group D F17 Disable Enable
Set repeat relays to follow logic
F18
Disable Enable
Set repeat relays to follow input
F19
Disable Enable
Set repeat relays to follow lamps
F18 & F19
Disable Enable
Repeat relays inhibited on test F20 Disable Enable
Set alarm to critical group relay F21* Disable Enable
Set alarm to non critical group relay F22* Disable Enable
Set alarm to critical horn relay F23* Disable Enable
Set alarm to non critical horn relay F24* Disable Enable
Note 1:- The Functions marked with the * are the default settings if no programming is requested with
the order
Note 2:- Functions F2, F18 & F19 are only available if individual channel repeat relays are fitted
(Option RLY).
