RTK Series 725 Annunciator
70
23.2 Alarm Card DIL Switch SW1 Address Settings
ADDRESS 64 32 16 8 4 2 1
NO. BINARY SW1-7 SW1-6 SW1-5 SW1-4 SW1-3 SW1-2 SW1-1
0 0000000 OFF OFF OFF OFF OFF OFF OFF
1 0000001 OFF OFF OFF OFF OFF OFF ON
2 0000010 OFF OFF OFF OFF OFF ON OFF
3 0000011 OFF OFF OFF OFF OFF ON ON
4 0000100 OFF OFF OFF OFF ON OFF OFF
5 0000101 OFF OFF OFF OFF ON OFF ON
6 0000110 OFF OFF OFF OFF ON ON OFF
7 0000111 OFF OFF OFF OFF ON ON ON
8 0001000 OFF OFF OFF ON OFF OFF OFF
9 0001001 OFF OFF OFF ON OFF OFF ON
10 0001010 OFF OFF OFF ON OFF ON OFF
11 0001011 OFF OFF OFF ON OFF ON ON
12 0001100 OFF OFF OFF ON ON OFF OFF
13 0001101 OFF OFF OFF ON ON OFF ON
14 0001110 OFF OFF OFF ON ON ON OFF
15 0001111 OFF OFF OFF ON ON ON ON
16 0010000 OFF OFF ON OFF OFF OFF OFF
17 0010001 OFF OFF ON OFF OFF OFF ON
18 0010010 OFF OFF ON OFF OFF ON OFF
19 0010011 OFF OFF ON OFF OFF ON ON
20 0010100 OFF OFF ON OFF ON OFF OFF
21 0010101 OFF OFF ON OFF ON OFF ON
22 0010110 OFF OFF ON OFF ON ON OFF
23 0010111 OFF OFF ON OFF ON ON ON
24 0011000 OFF OFF ON ON OFF OFF OFF
25 0011001 OFF OFF ON ON OFF OFF ON
26 0011010 OFF OFF ON ON OFF ON OFF
27 0011011 OFF OFF ON ON OFF ON ON
28 0011100 OFF OFF ON ON ON OFF OFF
29 0011101 OFF OFF ON ON ON OFF ON
30 0011110 OFF OFF ON ON ON ON OFF
31 0011111 OFF OFF ON ON ON ON ON
32 0100000 OFF ON OFF OFF OFF OFF OFF
33 0100001 OFF ON OFF OFF OFF OFF ON
34 0100010 OFF ON OFF OFF OFF ON OFF
35 0100011 OFF ON OFF OFF OFF ON ON
36 0100100 OFF ON OFF OFF ON OFF OFF
37 0100101 OFF ON OFF OFF ON OFF ON
38 0100110 OFF ON OFF OFF ON ON OFF
39 0100111 OFF ON OFF OFF ON ON ON
40 0101000 OFF ON OFF ON OFF OFF OFF
