RTK Series 725 Annunciator

F20- Inhibit Group Repeat Relays On System Test

If any channel in the system has been assigned to either the GPA or GPB relays using function F21

or F22 and system test is pressed the group relays will activate. However if function F20 is enabled

the GPA and GPB relays cannot be triggered by system test.

FEATURE-F20 STATUS LED

Set Channel To Operate The GPA & GPB Relays On System Test OFF

Set Channel To Inhibit The GPA & GPB Relays On System Test ON

F21- Critical Group Relay (GPA)

Each channel can be set to operate the critical group relay using function F21. When set the alarm

channel will activate the group relay when an alarm occurs and the relay will remain active until the

alarm has returned to normal and the channel has been acknowledged and reset.

FEATURE-F21 STATUS LED

Remove channel from the critical group relay OFF

Set channel to operate the critical group relay ON

F22- Non-Critical Group Relay (GPB)

Each channel can be set to operate the non-critical group relay using function F22. When set the

alarm channel will activate the group relay when an alarm occurs and relay will remain active until the

alarm has returned to normal and the channel has been acknowledged and reset.

FEATURE-F22 STATUS LED

Remove channel from the non-critical group relay OFF

Set channel to operate the non-critical group relay ON

F23- Critical Audible Relay (HNA)

Each channel can be set to operate the critical horn relay using function F23. When set the alarm

channel will activate the horn relay when an alarm occurs and the relay will remain active until the

mute or acknowledge pushbutton has been pressed.

FEATURE-F23 STATUS LED

Remove channel from the critical horn relay group OFF

Set channel to operate the critical horn relay ON

F24- Non-Critical Audible Relay (HNB)

Each channel can be set to operate the non-critical horn relay using function F24.

When set the alarm channel will activate the horn relay when an alarm occurs and the relay will

remain active until the mute or acknowledge pushbutton has been pressed.

FEATURE-F24 STATUS LED

Remove channel from the non-critical horn relay group OFF

Set channel to operate the non-critical horn relay ON
