RTK Series 725 Annunciator

Alarm Card DIL Switch SW1 Address Settings 121 To 127

ADDRESS 64 32 16 8 4 2 1

NO. BINARY SW1-7 SW1-6 SW1-5 SW1-4 SW1-3 SW1-2 SW1-1

121 1111001 ON ON ON ON OFF OFF ON

122 1111010 ON ON ON ON OFF ON OFF

123 1111011 ON ON ON ON OFF ON ON

124 1111100 ON ON ON ON ON OFF OFF

125 1111101 ON ON ON ON ON OFF ON

126 1111110 ON ON ON ON ON ON OFF

127 1111111 ON ON ON ON ON ON ON
