Ruida Technology RDC6432G - Section 4 Mainboard Interface Signal Description

RDC6432G control system user manual V1.1
SHENZHEN RUIDA TECHNOLOGY
10
Section 4 Mainboard
Interface Signal
Description
CONTENTS:
Main power connector power
Mainboard and display connector HMI
Udisk Interface
PC-USB Interface
General/dedicated OUTPUT
Dedicated/ General input interface INPUT
Three-axis limit input interface LIMIT
X/Y/U Three-axis drive interface AXIS_X~AXIS
Laser power control interface
