8.1.2 Key function description

“RESET”
：
Reset system

“RUN/PAUSE”
：
Start job or pause / restart job

“PULSE”
：
Laser tube pulse
（
Note: Press ‘Shift ’+‘Pulse’ for continuous pulse)

“STOP”
：
Stop processing/Motor axis movement

“FOCUS”
：
Auto Focus

“MANU”
：
User parameters, manufacturer parameters, language
settings etc.

“FRAME”
：
Perform border operation on the current processing file

“FILE”
：
Memory file and U disk file management
 "Origin" : Set the positioning point (Note: Press and hold ‘Shift’ + ‘Z-Origin’ to set
the current coordinate of the Z axis as the focus point)

“ESC”
：
Used to return to the previous menu, cancel parameter settings, etc.

“ENT”
：
Enter
 Arrow keys: used to move the X axis and Y axis or to move options when
setting parameters in the menu, adjust the value size, etc. (Note: Press and hold ‘Shift’ + ‘X, Y’ to
switch to fast movement mode)
