Web-based Configuration Guide 1 Network Settings
40
The traffic will be spread across multiple links according to the weight of each
WAN port. Larger traffic will be distributed to the WAN port with a higher
weight.
When you select this mode, you must specify the weight of each WAN port.
For example, if WAN and WAN 1 weight are set to 3 and 2 respectively, 60%
of the total traffic will be routed over WAN and 40% over WAN 1.
All traffic is routed over the primary interface. Once the primary interface fails,
traffic will be switched over to the secondary interface.
If there are multiple primary or secondary interfaces, please configure their
weight. (See balanced mode.)
After you set the load balancing mode to balanced, you can configure load balancing policies.
Table 3-2 Load balancing policies
After you enable this policy, the traffic is routed over multiple links based on
the links. Packets with the same source IP address, destination IP address,
source port, destination port, and protocol are routed over the same link.
