Model 2010D Gas Dilution Calibrator Specifications
Pneumatics:
 Flow accuracy + 1.0% of full scale
 Flow repeatability + 0.15% of full scale
 Flow linearity + 0.5% of full scale
Diluent:
 Mass flow controller range 0 - 10 SLPM (Optional 0 - 20 SLPM)
 Input pressure 20 - 30 PSIG
 Port 1, normally air (Optional Port 2, user defined)
Source:
 Mass flow controller range 0 - 100 SCCM (Optional 0 - 20 SCCM,
0 - 50 SCCM, 0 - 200 SCCM, 0 - 500 SCCM, 0 - 1 SLPM, 0 - 2 SLPM)
 Optional second source mass flow controller
 Input pressure 15 - 30 PSIG
 Four gas cylinder input ports (Optional two additional ports)
 Source manifold purge port
 Optional external permeation oven input port
 Usable dilution ratio varies with flow controller selection, add
a second source flow controller for wider dynamic range
 Solenoid valves for diluent, source and purge ports
 Eight calibration gas output ports
 Optional output solenoid valve
 GPT reaction chamber meets EPA requirements
 Attains 95% of Set Point in less than 60 Seconds
 Wetted surfaces are composed of stainless steel, Teflon, Peek,
Halar or glass; all ports Swagelok or equivalent; Viton and Calrez
seals
