System Operations Page 3-
Section 3 System Operation
This section presents general information about the operation of
the Model 2010D Calibration System.
Front Panel Guide
The Model 2010D front panel consists of a twenty-five line by
eighty character electroluminescent or color display, an optional
power switch and forty two buttons for system operation. A drawing
of the 2010D's front panel is shown in Figure 3-1.
The front panel buttons are used for entering commands and
information into the Model 2010D. Provision is also made to
support a standard IBM PC compatible PS2 style keyboard (which
plugs into the rear panel). If an external keyboard is used,
each of the front panel buttons have equivalent keys. In
addition, there are several shortcuts available on an external
keyboard that are impractical or unavailable from the front
panel.
Following the front panel drawing is a listing of the 2010D
front panel buttons and their functions. If the equivalent
external key is not obvious from the button name, it is
indicated in parentheses.
