5 - Information / Configuration
F@st™ 2804v2 Reference Manual - 253329475-A
Page 5-94 Sagemcom document. Reproduction and disclosure prohibited
Field State
Class Name
Traffic Class Name.
MARK
DSCP Mark
DSCP priority (from Default to CS7, see the first table of
this chapter).
Queue ID
Queue number, allocated by the system according to the
selected precedence.
802.1PMark
Priority field 802.1P (value between 0 and 7).
TRAFFIC CLASSIFICATION
RULES
LAN port
Nature of the LAN port.
Protocol
Protocol used.
DSCP
Differentiated Services Code Point, priority value from
Default to CS7, see the first table of this chapter.
Source
Addr./Mask
"Source" address (your computer, for example) and
associated subnet mask.
Source
Port
"Source" port.
Dest.
Addr./Mask
"Destination" address (a machine on the Internet, for
example) and associated subnet mask.
Dest.
Port
"Destination" port.
Source
MAC
Addr./Mask
"Source" MAC address (your computer, for example) and
associated subnet mask.
Destination
MAC
Addr./Mask
"Destination" MAC address (a machine on the Internet,
for example) and associated subnet mask.
802.1P
Priority field 802.1P (value between 0 and 7).
Order
Sequence number.
Enable/Disable
QoS enabled or disabled for this traffic class.
Note: This status can be amended starting from this
window.
