SAGEMCOM F@ST 2804v2 - Characteristics of the Different Interfaces

Annex D - Technical Characteristics
F@st™ 2804v2 Reference Manual - 253329475-A
Sagemcom document. Reproduction and disclosure prohibited Page D-3
D.2 Characteristics of the different interfaces
ADSL / ADSL2 / ADSL2+ Interface
Standards supported
• G.992.1 (ADSL), G.992.3 (ADSL2), G.992.5 (ADSL2+),
• G.994.1 (G.Handshake)
Transmission Code
• DMT
Maximum upward
transmission rate
• 24,5 Mbit/s
Maximum downward
transmission rate
• 1,3 Mbit/s
Latence
• Simple (Fast or interleaved)
TX Power
• 12,5 dB
Access Impedance
• 100
Ω
Range
• According to standard G.992.1 table Annexe G
Connection technology
• RJ11
Interface LAN Ethernet
Rate
• 10 Mbit/s or 100 Mbit/s, self-configurable
• Half / Full Duplex
Standard
• IEEE 802.3
Connection technology
• RJ45
• Type MDI or MDI-x self-detecting port
• Crossed or straight cord
USB Interface (Master)
Rate
• 1,5 Mbit/s to 480 Mbit/s
Standard
• USB 2.0
Data
• Asynchronous
Transmission Mode
• bidirectional
Power Supply
• 5 V - 500 mA maximum
Connection technology
• USB - Type A
