2.3 Installing your F@st
TM
2804v2
2.3.1 Powering up
¾ First connect the end of the mains adapter lead, supplied with the equipment, to the PWR
socket on your Residential Gateway,
¾ Connect the adapter to a nearby power outlet,
¾ Switching on,
¾ The
LED will light up first, followed by the four Ethernet LEDs (1 to 4), then these last
four LEDs will be off. The
and Ethernet (which corresponds to the connected interface)
LEDs should be steady and the
LED blinks during the establishment of the ADSL link,
then steadies like the
LED. The LED should be steady and turn from "Red" to
"Green" when a PPP session has been created.
Note: It lasts around one minute.
2.3.2 Connecting the ADSL cable
¾ Connect one end of the RJ11/RJ11 cable supplied with the equipment to the ADSL socket
of your Residential Gateway.
¾ Connect the other end of this cable as shown in the Figure 2.3.
