SAGEMCOM F@ST 2804v2 User Manual

2 - Description and connection of your router
F@st™ 2804v2 Reference Manual - 2533329475-A
Page 2-2 Sagemcom document. Reproduction and disclosure prohibited
2.1 Description
Figure 2.1 gives an overview of the router (F@st
TM
2804v2).
Figure 2.1 - Overview of case
This case consists principally of a lid and a base. Inside is a printed circuit equipped with
electronic components.
The front face of the lid has five display LEDs (see § 2.1.2).
The base has the LED ideograms, manufacturer's logo or the operator's logo.
Below the base is a label on which the product's identification code, series number and barcode
are shown.

SAGEMCOM F@ST 2804v2 Specifications

General

Brand	SAGEMCOM
Model	F@ST 2804v2
Category	Network Router
Language	English
