SAM4s SPS-2000 Operator Manual v1.18 Introduction • 13
Terminal Controls & Connections
Front Panel Angle Adjustment
Standard
Magnetic Card
Reader (MCR)
Front Panel Power Button
Press and hold the Front Panel
Power Button to alternately shut
down or activate the touch screen.
ote that the main power switch is
located on the bottom of the
terminal in the right-rear corner.
The front panel power button may
be enabled or disabled in the S-
Mode options program.
Set the position of the front
anel support to adjust the
angle of the front panel
from 22° to 77°.
The Error light
will flash
during IRC
communication
