II.USERS
IM TEMI 770E_C 2nd Edition: Sep. 1. 2003. 4/40
4. Operation & Setup
4-1. PROGRAM STOP
Figure 4-1 PROGRAM STOP
① Main page(Figure 3-4)
② Temp : Present temperature.
③ PTNO : Present Program pattern number.
User can set up pattern number, wised run.
④ Date & Time : It show present date & time also it is functioning turn off / on LCD back light.
Even if turn off the light automatically, controller still working and turn on the light
if user touch any point.
Back Light will be turn off automatically for saving Back Light life.
(Default : 10min) See Function 5-1
⑤ Program name
⑥ Start : Start a program and it is turning into STOP .
⑦ Humi : Present humidity.
⑧ State : Present working state.
■ RESERVE : Reserved working.(See 5-2. RESERVE)
■ PTEND : When the program finish, display PTEND.
⑨ Segment No : Present Segment number.
⑩ Alarm : Present Alarm state.
⑪ Display state of finish the running. (Display RUN DATE after set the RESERVE RUN)
When the select ⑥ on Figure 4-1, ③, ⑧ and ⑨ on Figure 4-2,
CONFIRM window appear.(Figure 5-4-9)
At this CONFIRM window, you can confirm if you really want doing job or not.
①
②
③
④
⑤
⑥
⑦
⑨
⑧
⑩
To Next Page
