III : COMMUNICATION
IM TEMI 770E_C 2nd Edition: Sep. 1. 2003. 15/21
4.3 Reservation
RESERVATION group is consisted confirm time, setting & reservation time D-Register.
■ Setting Time D-Register
D-Reg. Symbols Descriptions Read Write
D0201 N_YEAR TEMI 770 Present time (year) ○ ×
D0202 N_MONTH TEMI 770 Present time (month) ○ ×
D0203 N_DAY TEMI 770 Present time (day) ○ ×
D0204 N_HOUR TEMI 770 Present time (hour) ○ ×
D0205 N_MIN TEMI 770 Present time (min) ○ ×
D0206 RUN_YEAR TEMI 770 Reservation time (year) ○ ○
D0207 RUN_MONTH TEMI 770 Reservation time (month) ○ ○
D0208 RUN_DAY TEMI 770 Reservation time (day) ○ ○
D0209 RUN_HOUR TEMI 770 Reservation time (hour) ○ ○
D0210 RUN_MIN TEMI 770 Reservation time (min) ○ ○
D0211 SET_YEAR Setting time (year) × ○
D0212 SET_MONTH Setting time (month) × ○
D0213 SET_DAY Setting time (day) × ○
D0214 SET_HOUR Setting time (hour) × ○
D0215 SET_MIN Setting time (min) × ○
■ Reservation ON/OFF
D-Reg. Symbols States Value Descriptions
OFF 0 CANCEL
D200 RESERVE
ON 1 SET
