Samwontech TEMI770 User Manual

III : COMMUNICATION
IM TEMI 770E_C 2nd Edition: Sep. 1. 2003. 5/21
3.4 RSD Command
This command for reading D-Register orderly.
■ Transmission Format
Byte 1 2 3 1 2 1 4 2 1 1
S C L
T
Command
element
X
Addr RSD ,
Parameter
number
, D-Reg. No. SUM
RF
■ Response
Byte 1 2 3 1 2 1 4 1 4 1 …
S
T
Command
element
X
Addr RSD , OK , dddd-1 , dddd-2 , …
1 4 1 4 2 1 1
CL
, dddd-(n-1) , dddd-(n) SUM
RF
- Parameter number : 1 ~ 32
- dddd : Indicates a character string in hexadecimal format.
ex) When reading the D-Register from Temp PV(D0001) to Huni SP(D0006)
- Transmission : [stx]01RSD,06,0001[cr][lf]
- Transmission(Include Check Sum) : [stx]01RSD,06,0001C9[cr][lf]
([stx] = 0x02, [cr] = 0x0d, [lf] = 0x0a)
