Samwontech TEMI770 User Manual

III : COMMUNICATION
IM TEMI 770E_C 2nd Edition: Sep. 1. 2003. 7/21
3.6 WSD Command
This command for writing D-Register orderly.
■ Transmission Format
Byte 1 2 3 1 2 1 4 1 4 1 …
S
T
Command
element
X
Addr WSD ,
Parameter
number
, D-Reg. No1 , dddd-1 , …
1 4 1 4 2 1 1
CL
, dddd-(n-1) , dddd-(n) SUM
RF
■ Response
Byte 1 2 3 1 2 2 1 1
S C L
T
Command
element
X
Addr WSD , OK SUM
RF
- Parameter number : 1 ~ 32
- dddd : Indicates a character string in hexadecimal format.
ex) When the writing Temp SP(D0102) and Humi SP(D0103) as the FIX Running.
- Setting Temp SP : 50.0 ℃→Delete decimal point(500)→Hexadecimal(0x01F4)
- Setting Humi SP : 80.0 %→Delete decimal point(800)→Hexadecimal(0x0320)
- Transmission : [stx]01WSD,02,0102,01F4,0320[cr][lf]
- Transmission(Include Check Sum) : [stx]01WSD,04,0102,01F4,0320C4[cr][lf]
