Samwontech TEMI770 User Manual

II.USERS
IM TEMI 770E_C 2nd Edition: Sep. 1. 2003. 15/40
5-4-2. REPEAT
Select REPEAT at the Program page(Figure 5-4-1) for switching the REPEAT page.
Figure 5-4-6 REPEAT
① PTNO
: Pattern number.(1~120)
② LINK (0 ~ 120)
: When the finish the running pattern, set the next pattern no. continually.
③ PT REPEAT NO(0 ~ 999)
: Set repeat no. of set pattern no.
☞ 0(zero) is repeating unlimitedly.
④ START SEGMENT NO. (0 ~ 99)
: Set the start segment no. of repeat parts.
⑤ END SEGMENT NO. (0 ~ 99)
: Set the end segment no. of repeat parts.
⑥ COUNT NO(0 ~ 99)
: Set the no. of repeat of parts.
(Table 5-4) REPEAT PARAMETER
Name Function Valid Range Unit Default Value
PTNO PATTERN NO 1 ~ 120 ABS 1
LINK LINK PT 0 ~ 120 ABS 1
PT REPEAT PATTERN REPEAT 0 ~ 999 ABS 1
START START SEGMENT 0 ~ 99 ABS 0
END END SEGMENT 0 ~ 99 ABS 0
COUNT COUNT 0 ~ 99 ABS 0
Repeat of parts
