III : COMMUNICATION
IM TEMI 770E_C 2nd Edition: Sep. 1. 2003. 2/21
2. Communication Terminal Arrangement
TEMI 770 communication terminal arrangement is depends on option (RS232C or RX485)
Detail in as below.
2.1 Terminal RS232C and TEMI 770 9 Pin connector
2.2 Terminal RS485 and TEMI 770's terminal
SG
SHIELD
RTX+
RTX-
SG
SG
RTX-
RTX+
RTX+
RTX-
항
2
3
7
8
5
RD
TD
RTS
CTS
SG
SHIELD
Master Station
(D-Sub 9 Pin)
2
3
RXD
TXD
5SG
TEMI 500
(D-Sub 9 Pin Female)
Controller
(Terminal)
Controller
(Terminal)
Termination
Resistance
Termination
Resistance
Class 3 Ground Class 3 Ground
Master
Station
