5-6-6. ALARM
Select ALARM at the SETUP page(Figure 5-6-1) for switching the ALARM page.
Figure 5-6-13 ALARM
① ITEM
: Alarm mode.(Temp/Humi)
② TYPE
: Alarm type.
③ POINT
: Alarm value.(-100~100%)
④ HYSTERESIS
: Set HYSTERESIS on Alarm.
Alarm is still working even if on STOP mode.
(Table 5-14) ALARM PARAMETER
Name Function Valid Range Unit Default Value
ITEM ITEM TEMP, HUMI ABS TEMP
TYPE ALARM TYPE 1 ~ 20(See Figure 5-15) ABS 1
POINT ALARM POINT EUS(-100 ~ 100%) EU EU(0%)
HYS ALARM HYSTERESIS EUS(0 ~ 100%) EUS EUS(0.5%)
Switching
To Next Page
