Samwontech TEMI770 User Manual

III : COMMUNICATION
IM TEMI 770E_C 2nd Edition: Sep. 1. 2003. 11/21
4. D-REGISTER
D-Register is group of data which can using with communication all of TEMI 770's condition. Each group has 100
registers and these are classified as follows;
D-Register Range Groups Descriptions Read Write
D0001~D0099 PROCESS Basic process display ○ ×
D0100~D0199 FUNCTION Operation info display ○ ○
D0200~D0299 RESERVATION Time & Reservation ○ △
D0300~D0399 IS Inner Signal ○ ○
D0400~D0499 ALARM Alarm ○ ○
D0500~D0599 TEMP PID Temp P.I.D ○ ○
D0600~D0699 HUMI PID Humi P.I.D ○ ○
D0700~D0799 COMM. Communication ○ ×
D0800~D0899 OUTPUT Output ○ ○
D0900~D0999 INPUT Input ○ ○
D1000~D1099 PROGRAM Program ○ ○
D1100~D1199 RESERVED BLANK × ×
D1200~D1299 PTTN_INFO Program pattern INFO ○ ×
D1300~D1399 FILE1 Temp of TSP of pattern ○ ×
D1400~D1499 FILE2 Humi of TSP of pattern ○ ×
D1500~D1599 FILE3 Time of pattern ○ ×
D1600~D1799 PROG_INFO1,2 Basic INFO of program pattern ○ ○
D1800~D1999 PROG_TS1,2
On on/off mode of T1 or T2,
set the segment for TS1, TS2
○ ○
Each D-Registers are consisted hexadecimal 4charater(2-Byte).
