III : COMMUNICATION
IM TEMI 770E_C 2nd Edition: Sep. 1. 2003. 17/21
5. Set program pattern
5.1 Program
PROGRAM group is consisted program pattern setting D-Register.
How to set a program pattern is :
Set one by one with changing number of segment on TEMI 770.
■ Program pattern setting D-Register
D-Reg. Symbols Value Descriptions
D1000 P_PTNO 1~30 Set program number to Read or Write
D1001 DEST_PTNO 1~30 Set pattern number to Copy
0 Set for Read or Write on D1600~D1755
D1002 P_SEGNO
1~99 Set segment to Read or Write
1 INIT : D1000~D1004 value set '0'
2 READ : Reading value of D1000 and D1002
3 WRITE : Write value of D1000 and D1002
4 PT COPY : Copy pattern D1000 to D1001
5 PT DEL : Delete pattern on D1000
6 SEG INSERT : Insert segment on D1000 and D1002
7 SEG DEL : Delete segment on D1000 and D1002
D1003 TRIGGER
8 ALL PT : Display pattern of D1000 to D1300 …
0 FULL : Full memory for pattern or segment
1 DONE : Complete D1003(TRIGGER)'s job
2 PT EMPTY : Empty pattern
3 SEG EMPTY : Empty segment
4 PT RUN : PROG RUN state
5 PARA ERROR : Setting error on D1000~D1003
D1004 ANSWER
6 PT USED : PROG RUN by pattern
D1010 TEMP_TSP - Target set temp(TSP) for Read or Write
D1011 HUMI_TSP - Target set humi(TSP) for Read or Write
D1012 SEG_TIME - Segment time for Read or Write
To Next Page
