III : COMMUNICATION
IM TEMI 770E_C 2nd Edition: Sep. 1. 2003. 13/21
■ Share running D-Register
D-Reg. Symbols Descriptions
D0001 TEMP_NPV Present Temp PV
D0002 TEMP_NSP Present Temp SP
D0003 WET_NPV Present wet part Temp PV
D0004 WET_NSP Present wet part Temp SP
D0005 HUMI_NPV Present Humi PV
D0006 HUMI_NSP Present Humi SP
D0007 TEMP_MVOUT Output of Temp
D0008 HUMI_MVOUT Output of Humi
D0009 PIDNO Number of running P.I.D.
■ FIX running D-Register
D-Reg. Symbols Descriptions
D0020 PROC_TIME_H FIX running PROCESS TIME (hour)
D0021 PROC_TIME_L FIX running PROCESS TIME (min)
■ PROGRAM running D-Register
D-Reg. Symbols Descriptions
D0025 PTNO Number of running program pattern
D0026 SEGNO Number of running segment
D0027 R_TIME_H Time(hour) Number of running segment
D0028 R_TIME_M Time(min) Number of running segment
D0029 WAITTIME_H WAIT TIME hour) of waiting
D0030 WAITTIME_M WAIT Teeming) of waiting
D0031 N_PT_RPT Repeat times of present running pattern
D0032 PT_RPT Repeat times of setting pattern
D0033 N_SEG_RPT Repeat times of running segment
D0034 SEG_RPT Repeat times of setting pattern
D0035 P_TEMP_TSP Previous segment Temp TSP
D0036 N_TEMP_TSP Present segment Temp TSP
D0037 P_HUMI_TSP Previous segment Humi TSP
D0038 N_HUMI_TSP Present segment Humi TSP
D0039 N_SEG_TIME Setting time present segment
To Next Page
