Denite Time 1 Min. TripThis is the current (in primary amperes) at which the
Denite Time 1 element picks up. (Range: 6-16,000; Step: 1) The stated maximum is
for 15-kV IntelliRupter fault interrupters; 27-kV and 38-kV are limited to 12,500 amps
maximum.
Denite Time 1 Min. TimeThis is the time delay (in seconds) after which the Denite
Time 1 element trips. (Range: 0.000-600.000; Step: 0.001)
Denite Time 2 Min. TripThis is the current (in primary amperes) at which the
Denite Time 2 element picks up. (Range: 6-16,000; Step: 1) The stated maximum is
for 15-kV IntelliRupter fault interrupters; 27-kV and 38-kV are limited to 12,500 amps
maximum.
Denite Time 2 Min. TimeThis is the time delay (in seconds) after which the Denite
Time 2 element trips. (Range: 0.000-600.000; Step: 0.001)
Negative Sequence
The Negative Sequence element trips the IntelliRupter fault interrupter when the
negative sequence component of the three-phase elements exceeds the pickup value for
the time value set by the inverse curve or the denite time delay.
Negative Sequence Check box—Check to enable this element.
Inverse SegmentSelect from the drop-down list of inverse curve names or select
the None option. Only the Denite Time settings will be used when the None option
is selected.
Min. TripThis is the current (in primary amperes) at which the inverse curve begins
timing. (Range: 6-16,000; Step: 1) The stated maximum is for 15-kV IntelliRupter fault
interrupters; 27-kV and 38-kV are limited to 12,500 amps maximum.
Min. TimeThis is the time (in seconds) dening the fastest response of the inverse
curve portion of the TCC curve. (Range: 0.000-100.000; Step: 0.001)
Time MultThis is the time modier for the inverse curve. (Range: 0.01-15.00; Step: 0.01)
Time AdderThis is the time modier for the inverse curve. (Range: -10.000-100.000;
Step: 0.001)
Low Cutoff—This is the current (in primary amperes) at which the TCC curve begins
timing. This value must be equal to or greater than the lowest pickup value of the inverse
curve, the Denite Time 1 element, and the Denite Time 2 element. (Range: 6-16,000;
Step: 1) The stated maximum is for 15-kV IntelliRupter fault interrupters; 27-kV and
38-kV are limited to 12,500 amps maximum.
ResetSelect the reset method for the inverse curve from the drop-down list. Select
the D/T (Denite Time) or E/M (Electromechanical) mode.
Reset TimeWhen the Denite Time reset mode is selected, enter the reset delay time
(in seconds). (Range: 0.000-600.000; Step: 0.001)
Denite Time 1 Min. TripThis is the current (in primary amperes) at which the
Denite Time 1 element picks up. (Range: 6-16,000; Step: 1) The stated maximum is
for 15-kV IntelliRupter fault interrupters; 27-kV and 38-kV are limited to 12,500 amps
maximum.
102 S&C Instruction Sheet 766-530
Protection Setup
