Sanyo PLC-XU301A User Manual

23
Basic Operation
RotatetheZoomRingtozoominandout.
RotatetheFocusRingtoadjustthefocusoftheimage.
Zoom and Focus Adjustment
Ifaprojectedpicturestillhaskeystonedistortionafter
pressingtheAUTOSETUPbuttononthetopcontrolorthe
AUTOSETbuttonontheremotecontrol,correcttheimage
manuallyasfollows:
PresstheKEYSTONEbuttonontheremotecontrol.The
Keystonedialogboxappears.UsethePoint▲▼buttonsto
correctkeystonedistortion.Thekeystoneadjustmentcanbe
stored(seepage46).
Reducetheupperwidth
withthePoint
▲button.
Reducethelowerwidth
withthePoint
▼button.
•Thewhitearrowsindicatethatthereisno
correction.
•Aredarrowindicatesthedirectionofcorrection.
•Anarrowdisappearsatthemaximumcorrection.
•IfyoupresstheKEYSTONEbuttononthe
remotecontroloncemorewhilethekeystone
dialogboxisbeingdisplayed,thekeystone
adjustmentwillbecanceled.
•Theadjustablerangeislimiteddependingonthe
inputsignal.
Keystone Correction
Remote Control
Autosetupfunctionisprovidedtoautomaticallyexecutethe
settingofAutosetup(includesInputsearch,AutoPCadj.
andAutoKeystonefunctions)inthesettingmenubyjust
pressingtheAUTOSETUPbuttononthetopcontrolorthe
AUTOSETbuttonontheremotecontrol.Refertopage45
forthesettingoftheAutosetupfunction.
Notes:
 •AutoKeystonecorrectsverticaldistortiononly;itdoes
notcorrecthorizontaldistortion.
 •AutoKeystonecannotworkwhenCeilingfeatureisset
toOnintheSettingmenu(p.50).
 •Perfectcorrectionoftheimagedistortioncannotbe
ensuredwiththeAutosetupfunction.Ifthedistortion
cannotbecorrectedproperlybypressingtheAUTO
SETUPorAUTOSETbutton,adjustmanuallyby
pressingtheKEYSTONEbuttonontheremotecontrol
orselectingKeystoneintheSettingmenu(p.46).
 •Fine sync,Total dots,HorizontalandVertical
positionofsomecomputerscannotbefullyadjusted
withtheAutoPCAdjustmentfunction.Whentheimage
isnotprovidedproperlywiththisoperation,manual
adjustmentsarerequired(pp.31-32).
AUTO SET button
Auto Setup Function
POINT ▲▼buttons
KEYSTONE button
Top Control
AUTO SETUP button
POINT ▲▼buttons
ZoomRing
FocusRing
