Sanyo PLC-XU301A User Manual

9
Part Names and Functions
Rear Terminal
② ③① ④
⑥
⑩
⑦⑨
⑧
⑤
⑥ S-VIDEO IN
 ConnecttheS-VIDEOoutputsignalfromvideo
equipmenttothisjack(p.16).
⑨ AUDIO IN
 Connecttheaudiooutputsignalfromvideo
equipmentconnectedto⑥or⑩tothisjack.
Foramonoaudiosignal(asingleaudiojack),
connectittotheL(MONO)jack(p.15).
⑧ COMPUTER 1 / COMPUTER 2 AUDIO IN
 Connecttheaudiooutput(stereo)froma
computerorvideoequipmentconnectedto②
or④tothisjack.(pp14,16)
⑩ VIDEO IN
 Connectthecompositevideooutputsignalto
thisjack(p.15).
②
 COMPUTER IN 1 / COMPONENT IN
 Connectoutputsignalfromacomputer,RGBscart
21-pinvideooutputorcomponentvideooutputto
thisterminal(pp.14,16).
⑦ AUDIO OUT (VARIABLE)
 Connectanexternalaudioamplifiertothisjack
(pp.14-16).
 ThisterminaloutputssoundfromAUDIOIN
terminal(⑧or⑨).
③ MONITOR OUT
 Thisterminalcanbeusedtooutputtheincoming
analogRGBsignalandcomponentsignalfrom
COMPUTERIN1/COMPONENTINterminalor
COMPUTERIN2/DVI-I)terminaltotheother
monitor(pp.14,16).
⑤ LAN Connection Terminal
 ConnecttheLANcable(refertotheowner’smanual
“NetworkSet-upandOperation”).
① CONTROL PORT
 Whentheprojectoriscontrolledbyacomputer,
connecttothisjackwithserialcontrolcable.
④ COMPUTER IN 2 / DVI-I
 Connectcomputeroutput(Digital/AnalogDVI-Itype)
tothisterminal(pp.14,16).
