Sanyo PLC-XU301A - Input Source Selection (Rgb(Pc Digital), Rgb; Hdcp))

28
Computer Input
ChooseComputer 2 (PC digital)orComputer 2 (AV HDCP) bypressingtheINPUTbuttononthetopcontrol
orpresstheCOMPUTER2buttonontheremotecontrol.
BeforeusingINPUTbutton,correctinputsourceshouldbeselectedthroughMenuoperationasdescribed
below.
Input Source Selection (RGB(PC digital), RGB(AV HDCP))
Direct Operation
Menu Operation
Note:
•WhentheInputSearchfunctionissettoOn1orOn2,the
inputsignalwillbesearchedautomatically(p.45).
•HDCP(High-bandwidthDigitalContentProtection)is
asystemforprotectingdigitalentertainmentcontent
deliveredbyDVI(DigitalVisualInterface)frombeing
copied.ThespecificationofHDCPisdecidedand
controlledbyDigitalContentProtection,LLC.Shouldthe
specificationbechanged,thisprojectormaynotdisplay
thedigitalcontentprotectedbyHDCP.
COMPUTER 2 button
Top Control
Remote Control
1
2
PresstheMENUbuttontodisplaytheOn-Screen
Menu.UsethePoint▲▼buttonstoselectInputand
thenpressthePoint►ortheSELECTbutton.
UsethePoint
▲▼buttonstoselectComputer 2and
thenpressthePoint►button.
Input Menu
RGB(PC digital)
NTSC
3
UsethePoint▲▼buttonstoselectRGB(PC digital)
orRGB(AV HDCP) andthenpresstheSELECT
button.
INPUT button
Computer 2 (PC digital)
Computer 2 (AV HDCP)
Computer 2 (Analog)
Computer
2
Video
Computer 2 (PC digital) /
(AV HDCP) /
(Analog)
S-video
Computer 1 ( RGB)
/(Component) / (Scart)
