Part Names and Functions
①
⑤ ⑨③②
Front
Back
④
①Infrared Remote Receiver
②Zoom Ring
③Focus Ring
④Projection Lens
⑤ Lens Cap
 (Seepage61forattaching.)

⑥Speaker
⑦Exhaust Vents
CAUTION
Hotairisexhaustedfromtheexhaustvent.Donotput
heat-sensitiveobjectsnearthisside.
⑧Lamp Cover
⑨Air Intake Vent
⑩Terminals and Connectors
⑪Top Controls and Indicators
⑫ LAN Connection Terminal
⑬ Power Cord Connector
⑭Filters
⑮Adjustable Feet

Note:
⑫
LANConnectionTerminalisfortheNetworkfunction.
Refertotheowner’smanualof“NetworkSet-upand
Operation”.
Kensington Security Slot
ThisslotisforaKensingtonlockusedtodetertheftof
theprojector.

KensingtonisaregisteredtrademarkofACCOBrands
Corporation.

CAUTION
Donotturnonaprojectorwithlenscapattached.High
temperaturefromlightbeammaydamagelenscapand
resultinfirehazard.
⑦
⑩
⑨
⑥
⑪
⑬
⑫
⑧

Bottom
⑮
⑭
