Sanyo PLC-XU301A - Dimensions

78
Appendix
Dimensions
Unit:mm(inch)
ScrewHolesforCeilingMount
Screw:M4
Depth:12.0(0.472)
93.5(3.68)
232.5(9.15)
121.9(4.80)
109.7(4.32)
143.3(5.64)
9.5 (0.37)
101(3.98)
107.6(4.24)
219.4(8.64)
23(0.91)
55(2.17)
25(0.98)
51.9 (2.05)
80.5(3.17)
12 MAX
º
3.8 (0.15)
42.3 (1.67)
24.8 (0.98)
40.8 (1.61)
<
<
<
<
<
