Manual PC Adjustment
SomecomputersemployspecialsignalformatswhichmaynotbetunedbyMulti-scansystemofthisprojector.
ManualPCAdjustmentenablesyoutopreciselyadjustseveralparameterstomatchthosesignalformats.The
projector has five independent memory areas to store those parameters manually adjusted. It allows you to
recallthesettingforaspecificcomputer.
1
2
UsethePoint◄►buttonstoadjustthevalue,eliminatinga
flickerfromtheimagedisplayed(from0to31).
Fine sync
UsethePoint◄►buttonstoadjustthenumberoftotaldots
inonehorizontalperiodtomatchyourPCimage.
Total dots
UsethePoint◄►buttonstoadjustthehorizontalpicture
position.
Horizontal
UsethePoint◄►buttonstoadjusttheverticalpicture
position.
Vertical
UsethePoint◄►buttonstoadjusttheclamplevel.When
theimagehasdarkbars,trythisadjustment.
Clamp
PresstheMENUbuttontodisplaytheOn-Screen
Menu.UsethePoint▲▼buttonstoselectPC adjust 
andthenpressthePoint►ortheSELECTbutton.
UsethePoint▲▼buttonstoselectthedesireditem
andthenpresstheSELECTbuttontodisplaythe
adjustmentdialogbox.UsethePoint◄►buttonsto
adjustthesettingvalue.
Use the Point ◄► buttons to adjust the vertical area
displayedbythisprojector.
Display area V
Use the Point ◄► buttons to adjust the horizontal area
displayedbythisprojector.
Display area H
