Satec PM172E User Manual

Appendix D Parameters for Data Log and Monitoring
128 Series PM172 Powermeters
Designation Description
PHASORS Phasors
V1 Mag
V1/V12 Voltage magnitude
1
V2 Mag
V2/V23 Voltage magnitude
1
V3 Mag
V3/V31 Voltage magnitude
1
I1 Mag I1 Current magnitude
I2 Mag I2 Current magnitude
I3 Mag I3 Current magnitude
V1 Ang
V1/V12 Voltage angle
1
V2 Ang
V2/V23 Voltage angle
1
V3 Ang
V3/V31 Voltage angle
1
I1 Ang I1 Current angle
I2 Ang I2 Current angle
I3 Ang I3 Current angle
DEMANDS
Present Demands (Power Demands
E
)
V1 DMD
V1/V12 Volt demand
1
V2 DMD
V2/V23 Volt demand
1
V3 DMD
V3/V31 Volt demand
1
I1 DMD I1 Ampere demand
I2 DMD I2 Ampere demand
I3 DMD I3 Ampere demand
kW IMP BD kW import block demand
kvar IMP BD kvar import block demand
kVA BD kVA block demand
kW IMP SD kW import sliding window demand
kvar IMP SD kvar import sliding window demand
kVA SD kVA sliding window demand
kW IMP ACC DMD kW import accumulated demand
kvar IMP ACC DMD kvar import accumulated demand
kVA ACC DMD kVA accumulated demand
kW IMP PRD DMD kW import predicted sliding window demand
kvar IMP PRD DMD kvar import predicted sliding window demand
kVA PRD DMD kVA predicted sliding window demand
PF IMP@kVA MXDMD PF (import) at Maximum kVA sliding window demand
kW EXP BD kW export block demand
kvar EXP BD kvar export block demand
kW EXP SD kW export sliding window demand
kvar EXP SD kvar export sliding window demand
kW EXP ACC DMD kW export accumulated demand
kvar EXP ACC DMD kvar export accumulated demand
kW EXP PRD DMD kW export predicted sliding window demand
kvar EXP PRD DMD kvar export predicted sliding window demand
HRM DMD Present Harmonic Demands
V1 THD DMD
V1/V12 THD demand
2
V2 THD DMD
V2/V23 THD demand
2
V3 THD DMD
V3/V31 THD demand
2
I1 THD DMD I1 THD demand
I2 THD DMD I2 THD demand
I3 THD DMD I3 THD demand
I1 TDD DMD I1 TDD demand
I2 TDD DMD I2 TDD demand
I3 TDD DMD I3 TDD demand
SUMM ACC DMD
Summary (TOU Total) Accumulated Demands
E
SUM REG1 ACC DMD
Summary register #1 demand
SUM REG2 ACC DMD
Summary register #2 demand
… …
SUM REG8 ACC DMD
Summary register #8 demand
SUMM BLK DMD
Summary (TOU Total) Block Demands
E
SUM REG1 BLK DMD
Summary register #1 demand
SUM REG2 BLK DMD
Summary register #2 demand
… …
SUM REG8 BLK DMD
Summary register #8 demand
SUMM SW DMD
Summary (TOU Total) Sliding Demands
E
SUM REG1 SW DMD
Summary register #1 demand
