Chapter 3 Display Operations Status Display
Series PM172 Powermeters 39
TOU Energy Register 1
1
rEG.1
trF.1
MWh
Tariff 1 reading
2
rEG.1
trF.2
MWh
Tariff 1 reading
8
rEG.1
trF.8
MWh
Tariff 8 reading
TOU Energy Register 8
1
rEG.8
trF.1
MWh
Tariff 1 reading
2
rEG.8
trF.2
MWh
Tariff 1 reading
8
rEG.8
trF.8
MWh
Tariff 8 reading
Status Display
The meter has separate status information pages accessible through the
primary device menu. The Status Display shows rarely used information that
is especially helpful when connecting the meter inputs and outputs to
external equipment. For information on navigating in the menus, see “Using
the Menus”.
To enter the Status Display:
1. From the Data Display, press the SELECT button to enter the
primary device menu. The “StA” window is highlighted.
2. Press ENTER to enter the Status Display. Use the UP and
DOWN arrow buttons to scroll through the status pages.
To exit the Status Display:
1. Press ESC to return to the primary device menu.
2. Press ESC to return to the Data display.
Status Display
1
PhS
rot
POS/nEG/Err
Phase rotation order
2
AG.
V1 angle
V2 angle
V3 angle
Voltage angles (±180°, referenced to
V1)
3
AG.
I1 angle
I2 angle
I3 angle
Current angles (±180°, referenced to
V1)
4 U.Unb
V% unb
Voltage unbalance, percent
5 C.Unb
I% unb
Current unbalance, percent
6
rEL
1.2.
00
Relay status
7
St.In
1.2.
00
Status inputs
S
T
S
T
S
T
ENERGY
ENTER
ENERGY
ENTER
St
A
CHG
OPS
SELECT
ENERGY
ENTER
